- Product Description
- Model Specification
-
- Commodity name: GEL VRLA Lead-Acid Motorcycle Starter Battery
- Commodity ID: M01002
Our factory has a complete motorcycle starter battery production line, using advanced technology, can produce more than 95% of motorcycle starter battery models.
Xinfu tech
GEL VRLA Lead-Acid Motorcycle Starter Battery
CHARACTERISTIC
1. 100% Pre-delivery inspection to ensure stable quality and reliable erformance.
2. Pb-Ca grid alloy battery plate, low water loss, and stable quality low self-discharge rate.
3. Complete sealed, maintenance free, low self-discharge rate, good sealing property.
4. Low Internal resistance, good high rate discharge performance.
5. Excellence high-and-low temperature performance, working temperature ranging from -30°C to 55°C.
6. Design float service life: 3-5 years.
Safe Use Precautions
I. Warning
1. The inside electrolyte will corrode metal, cotton product, stone. Use properly.
2. Do not place the battery against the side or upside down to prevent acid leakage
3. The hydrogen will be generated during the working and discharging of battery which will cause explosion if there were fire. Pay attention for the following
3.1. Maintain and use the battery where is ventilate
3.2. No sparks and flame when the battery is in maintenance
3.3. If the battery is charging outside the vehicle which can’t be installed immediately after finish charging until laying at lease 10min to release the hydrogen generated inside
the battery.
3.4. After riding, the battery can’t be dismounted immediately until laying for at least 10 mins
3.5. During charging, the ambient temperature should not be over 45 OC, Otherwise cooling by water or by reducing the charging current and charging volts.
4. DO NOT place the metal tool or conducting matter nearby the terminal in case short-circuit the terminal
5. DO not knock the terminal by hammer during the battery installation
6. Be safe during carrying to prevent hitting
II. Installation and Maintenance
1. Always connect the positive terminal firstly.
DO NOT reverse polarity otherwise the electrical equipment of motorcycle will damage.
Caution:
*Some can’t be activated due to the different performance of different vehicle. Start the engine for more times or step on gas which can more easily to activate.
*Manual activation is recommend to achieve exact date recorded.
2. During acid filling, wearing acid-proof cloths, rubber boots, shield glass and rubber glove etc.
If the skin and clothes are splashed by acid, wash by large quantity of water. Seek medical help if necessary.
3. DO NOT over discharging the battery, charging the battery timely after discharging.
4. Dismount or disconnect the negative terminal of battery if the motorcycle hasn’t been in service for long term.
5. DO NOT check the battery has power or not by short-circuit the terminal.
6. Regularly check the terminal connection and the surface of terminal is clean or not to ensure well connection.
7. Storage the battery where is 5~250C, dry, ventilated and no direct sunshine. Keep the battery at least 2m away from the heat source. Regularly check and maintain the battery.
Key words:- Motorcycle starter battery
- Motorcycle GEL battery
- GEL VRLA battery
- Motorcycle batteries
- Motorcycle GEL batteries
-
GEL VRLA Lead-Acid Motorcycle Starter Battery Products Catalogue No. Series Model Voltage (V) Capacity （Ah） Hour rate (HR) Dimension±2 (MM) Dimension (inch) Polarity Weight (KG) Terminal Regular Charge Current A Meter CCA (25±5℃) CCA (-18℃) 001 YB Series 6N4-BS(GEL） 6 4 10 71*71*93 2.8*2.8*3.66 + - 0.81 W 0.4 N/A 30 002 YB Series 12M5D-BS(GEL) 12 5 10 135*74*93 5.31*2.91*3.66 + - 1.83 C8 0.5 150 65 003 YB Series YB2.5L-BS(GEL) 12 2.5 10 80*77*105 3.15*3.03*4.13 - + 1.03 W 0.25 N/A 20 004 YB Series YB3L-BS(GEL) 12 3 10 98*56*109 3.86*2.2*4.29 - + 1.19 C6 0.3 80 35 005 YB Series YB5L-BS(GEL) 12 5 10 119*60*129 4.69*2.36*5.08 - + 1.77 C6 0.5 115 55 006 YB Series YB5L-BS(GEL) 12 5 10 119*60*129 4.69*2.36*5.08 - + 1.86 C6 0.5 80 50 007 YB Series YB6.5L-BS(GEL) 12 6.5 10 138*65*100 5.43*2.56*3.94 - + 1.98 C8 0.65 155 75 008 YB Series YB6.5L-BS(GEL) 12 6.5 10 138*65*100 5.43*2.56*3.94 - + 2.16 C8 0.65 140 75 009 YB Series YB7B-BS(GEL) 12 7 10 148*60*128 5.83*2.36*5.04 + - 2.21 C7 0.7 140 75 010 YB Series YB7BL-BS(GEL) 12 7 10 148*60*128 5.83*2.36*5.04 - + 2.21 C7 0.7 140 75 011 YB Series YB7-BS(GEL) 12 7 10 137*76*128 5.39*2.99*5.04 + - 2.54 C7 0.7 130 75 012 YB Series YB7L-BS(GEL) 12 7 10 137*76*128 5.39*2.99*5.04 - + 2.54 C7 0.7 130 75 013 YB Series YB7-BS(GEL) 12 8 10 137*76*128 5.39*2.99*5.04 + - 2.65 C7 0.8 140 85 014 YB Series YB7L-BS(GEL) 12 8 10 137*76*128 5.39*2.99*5.04 - + 2.65 C7 0.8 140 85 015 YB Series YB9-BS(GEL) 12 9 10 137*76*134 5.39*2.99*5.28 + - 2.7 C7 0.9 140 85 016 YB Series YB9-BS(GEL) 12 9 10 137*76*134 5.39*2.99*5.28 + - 2.8 C7 0.9 160 100 017 YB Series YB9-BS(GEL) 12 9 10 137*76*134 5.39*2.99*5.28 + - 2.95 C7 0.9 180 110 018 YB Series YB10L-BS(GEL) 12 10 10 132*88*145 5.2*3.46*5.71 - + 3.45 Z1 1 230 120 019 YB Series YB12A-BS(GEL) 12 12 10 134*78*156 5.28*3.07*6.14 + - 3.63 Z1 1.2 240 140 020 YB Series YB12AL-BS(GEL) 12 12 10 134*78*156 5.28*3.07*6.14 - + 3.63 Z1 1.2 240 140 021 YB Series YB14-BS(GEL) 12 14 10 132*88*163 5.2*3.46*6.42 + - 4.54 Z1 1.4 285 185 022 YB Series YB14L-BS(GEL) 12 14 10 132*88*163 5.2*3.46*6.42 - + 4.54 Z1 1.4 285 185 023 YB Series YB16L-BS(GEL) 12 19 10 173*100*152 6.81*3.94*5.98 - + 6.15 Z2 1.9 390 240 024 YB Series YB16CL-BS(GEL) 12 19 10 173*100*175 6.81*3.94*6.89 - + 6.25 C9 1.9 320 240 025 YB Series YB30L-BS(GEL) 12 30 10 166*127*175 6.54*5*6.89 - + 8.5 Z2 3 290 230 026 YB Series YB32L-BS(GEL) 12 32 10 166*127*175 6.54*5*6.89 - + 9.1 Z2 3.2 390 340 027 UT Series UTZ5S(GEL) 12 4 10 113*70*87 4.45*2.76*3.43 - + 1.3 C8 0.4 115 45 028 UT Series UTZ5S(GEL) 12 4 10 113*70*87 4.45*2.76*3.43 - + 1.4 C8 0.4 120 50 029 UT Series UTZ6V(GEL) 12 6 10 113*70*105 4.45*2.76*4.13 - + 2.02 C3 0.6 150 85 030 UT Series UTZ7S(GEL) 12 6 10 113*70*107 4.45*2.76*4.21 - + 2.02 C8 0.6 150 85 031 UT Series UTZ7V(GEL) 12 7 10 113*70*121 4.45*2.76*4.76 - + 2.28 C8 0.7 150 100 032 UT Series UTZ8V(GEL) 12 7 10 113*70*129 4.45*2.76*5.08 - + 2.24 C3 0.7 140 85 033 UT Series UTZ10S(GEL) 12 8.6 10 150*86*94 5.91*3.39*3.7 + - 2.85 Z1 0.86 220 120 034 UT Series UTZ12S(GEL) 12 11.2 10 150*86*111 5.91*3.39*4.37 + - 3.36 Z1 1.12 200 130 035 UT Series UTZ14S(GEL) 12 11.2 10 150*86*111 5.91*3.39*4.37 + - 3.52 Z1 1.12 230 150 036 UT Series UTX4L-BS(GEL) 12 4 10 113*70*85 4.45*2.76*3.35 - + 1.3 C8 0.4 115 45 037 UT Series UTX4L-BS(GEL) 12 4 10 113*70*85 4.45*2.76*3.35 - + 1.4 C8 0.4 120 50 038 UT Series UTX5L-BS(GEL) 12 5 10 113*70*107 4.45*2.76*4.21 - + 1.64 C8 0.5 125 55 039 UT Series UTX5L-BS(GEL) 12 5 10 113*70*107 4.45*2.76*4.21 - + 1.79 C8 0.5 130 70 040 UT Series YT7B-4(GEL) 12 6.5 10 150*65*94 5.91*2.56*3.7 + - 2.15 C9 0.65 150 80 041 UT Series UTX7L-BS(GEL) 12 7 10 113*70*130 4.45*2.76*5.12 - + 2.15 C8 0.7 135 75 042 UT Series UTX7L-BS(GEL) 12 7 10 113*70*130 4.45*2.76*5.12 - + 2.24 C8 0.7 140 85 043 UT Series UTX7A-BS(GEL) 12 7 10 150*86*94 5.91*3.39*3.7 + - 2.4 C9 0.7 180 90 044 UT Series UTX7A-BS(GEL) 12 7 10 150*86*94 5.91*3.39*3.7 + - 2.48 C9 0.7 185 100 045 UT Series YT9B-4(GEL) 12 8 10 150*70*105 5.91*2.76*4.13 + - 2.61 C9 0.8 185 100 046 UT Series UTX9-BS(GEL) 12 9 10 150*86*107 5.91*3.39*4.21 + - 2.93 C9 0.9 180 120 047 UT Series YT12A-BS(GEL) 12 9.5 10 150*86*107 5.91*3.39*4.21 + - 3.13 Z1 0.95 200 120 048 UT Series YT12A-BS(GEL) 12 10 10 150*86*107 5.91*3.39*4.21 + - 3.32 Z1 1 245 135 049 UT Series YT12B-4(GEL) 12 10 10 150*70*130 5.91*2.76*5.12 + - 3.12 C9 1 185 100 050 UT Series UTX12-BS(GEL) 12 10 10 150*86*130 5.91*3.39*5.12 + - 3.29 C9 1 180 100 051 UT Series UTX12-BS(GEL) 12 12 10 150*86*130 5.91*3.39*5.12 + - 3.87 Z1 1.2 210 140 052 UT Series UTX12-BS(GEL) 12 12 10 150*86*130 5.91*3.39*5.12 + - 4.12 Z1 1.2 240 165 053 UT Series YT14B-4(GEL) 12 12 10 150*70*145 5.91*2.76*5.71 + - 3.8 C9 1.2 185 115 054 UT Series UTX14-BS(GEL) 12 12 10 150*86*145 5.91*3.39*5.71 + - 4.4 Z1 1.2 220 150 055 UT Series UTX14L-BS(GEL) 12 12 10 150*86*145 5.91*3.39*5.71 - + 4.4 Z1 1.2 220 150 056 UT Series UTX14-BS(GEL) 12 14 10 150*86*145 5.91*3.39*5.71 + - 4.68 Z1 1.4 240 185 057 UT Series UTX14L-BS(GEL) 12 14 10 150*86*145 5.91*3.39*5.71 - + 4.68 Z1 1.4 240 185 058 UT Series UTX16-BS(GEL) 12 14 10 150*86*161 5.91*3.39*6.34 + - 5 Z1 1.4 235 165 059 UT Series UTX16L-BS(GEL) 12 14 10 150*86*161 5.91*3.39*6.34 - + 5 Z1 1.4 235 165 060 UT Series UTX16-BS(GEL) 12 16 10 150*86*161 5.91*3.39*6.34 + - 5.3 Z1 1.6 255 200 061 UT Series UTX16L-BS(GEL) 12 16 10 150*86*161 5.91*3.39*6.34 - + 5.3 Z1 1.6 255 200 062 UT Series YT20-4(GEL) 12 18 10 177*88*155 6.97*3.46*6.1 + - 5.9 Z2 1.8 290 200 063 UT Series YT20L-4(GEL) 12 18 10 177*88*155 6.97*3.46*6.1 - + 5.9 Z2 1.8 290 200 064 UT Series YT20-4(GEL) 12 20 10 177*88*155 6.97*3.46*6.1 + - 6.2 Z2 2 330 240 065 UT Series YT20L-4(GEL) 12 20 10 177*88*155 6.97*3.46*6.1 - + 6.2 Z2 2 330 240 066 UT Series UTX21L-BS(GEL) 12 21 10 205*91*159 8.07*3.58*6.26 - + 6.78 Z2 2.1 310 220 067 UT Series UTX24L-BS(GEL) 12 24 10 205*91*159 8.07*3.58*6.26 - + 7.4 Z2 2.4 400 320
